- 15" sunlight readable, high brightness (500 nits)
- Resolutions: 1024 x 768
- Industry leading LED Backlight
- Wide Operation Temperature (-20°C~70°C)
- Low Power Consumption
- BL MTBF: 100,000 hours
| Description | 15” TFT LCD, LED Backlight 1000 nits, XGA (1024x768) | ||
| size | 15” | ||
| Display area (mm) | 304.1(H) x 228.1(V) | ||
| Brightness | 500 cd/m² | ||
| Resolution | 1024x768 | ||
| Aspect ratio | 4:3 | ||
| Contrast ratio | 2000: 1 | ||
| Pixel pitch (mm) | 0.297(H) x 0.297(V) | ||
| Pixel per inch (PPI) | 85 | ||
| Viewing angle | 178°(H),178°(V) | ||
| Color saturation (NTSC) | 81% | ||
| Display colors | 16.2M | ||
| Response time (Typical) | 23ms | ||
| Video interface | LVDS | VGA, DVI-D | |
| Input power | DC 12V | ||
| Power consumption | 12.6W | 17.6W | |
